Your MCP server can't log into Google: you grabbed the OAuth client, not the service-account key

The MCP server had one job: read a Google Analytics property so an agent could stop guessing at traffic numbers. It failed auth on every call. Not a 401 from Google — a crash before the request even left the machine, which is worse, because a crash before the network is a crash you caused. I fed it the credentials file it asked for. The credentials file was wrong. It is always wrong, and it is wrong in the exact way Google’s download button encourages.

I can’t hand you my Analytics property to reproduce this. I don’t need to. Both failures that stop this integration happen before the first packet, in files and shell variables I can break on a bench and did — with jq 1.7, openssl 3.0.13, and Python cryptography 41.0.7. Everything below actually ran. The one thing I did not do is complete a live GA API call, so nowhere do I claim I did.

The wrong file has a tell in its name

Server-to-server tools — an MCP server, a cron job, a CI step — authenticate as a service account: a robot identity with its own private key. What Google’s “Create credentials” menu happily hands you instead, if you pick the wrong item, is an OAuth 2.0 client — the thing an app asking a human to click “Allow” uses. They are both JSON. They are not interchangeable. The OAuth client cannot authenticate a headless server, and the library will not tell you that in a sentence you’d recognize; it will just fail to build a credential.

The tell is right there in the filename. The OAuth client downloads as client_secret_827.apps.googleusercontent.com.json. If your credentials file ends in .apps.googleusercontent.com.json, stop — that is the wrong one. But filenames get renamed, so here is the test that reads the contents. A service-account key has a top-level "type": "service_account". An OAuth client has a top-level web or installed object and no type at all:

jq -r 'if .type == "service_account" then "service-account key ✅"
       elif has("web") or has("installed") then "OAuth client ❌ (wrong file)"
       else "not a Google credential ❌" end' creds.json

I ran it on both files:

service-account.json                                 -> service-account key ✅
client_secret_827.apps.googleusercontent.com.json    -> OAuth client ❌ (wrong file)

So the fix for failure #1: in Google Cloud Console, create a service account, add a key to it (JSON), download that, and grant that service account’s email — the ...@your-project.iam.gserviceaccount.com one — explicit Viewer access on the GA4 property under Admin → Property Access Management. The account exists; it still sees nothing until you invite it. The it-journey.dev walkthrough of this same integration covers the console clicks end to end; this post is about the two ways the file fights back after you’ve downloaded it.

The gauntlet: what the detector does when you feed it garbage

A test that only passes the two files you expected is not a test, it’s a demo. I fed the detector everything a tired person might actually point it at. Six inputs, run for real:

Five of six behaved. The emoji-newline filename didn’t faze jq — grudging respect, it reads the bytes and ignores the theatrics of the name. The third absurd input found the real bug, the way it always does: the empty file produced no output and exit code 0, so a || echo "bad" guard downstream never fires. You’d conclude “the check passed” from a zero-byte credential.

$ : | jq -r '.type'; echo "exit=$?"
exit=0

jq treats empty input as “no results,” not an error. The fix is -e, which makes jq exit non-zero when the result is null or the input is empty:

$ jq -e -r '.type' empty.json; echo "exit=$?"
exit=4

Put -e in the detector before you trust its exit code. One flag, one class of silent pass closed.

Failure #2: the env var that eats your private key

You found the right file. Now you do the thing every twelve-factor blog told you to do — put the secret in an environment variable instead of on disk — and it breaks again. A service-account key stores the private key as a JSON string with the newlines escaped, as literal backslash-n:

$ python3 -c "import json;print(repr(json.load(open('service-account.json'))['private_key'][:40]))"
'-----BEGIN PRIVATE KEY-----\nMIIEvQIBADAN'

Those \n are two characters — a backslash and an n — not a newline. A PEM key with its line breaks replaced by the two-character string \n is not a PEM key; it’s a string that starts with the right words. I wrote a validator that does exactly what a Google client library does under the hood — load_pem_private_key from cryptography — and fed it the key four ways. Every row ran:

A and B are the same mistake with two coats of paint: a real, openssl-generated 2048-bit RSA key, moved through a shell variable, refused to parse because the newlines arrived as literal \n. Row C is the one-line rescue if you’re stuck with the key in an env var — un-escape it before you hand it over:

private_key = os.environ["GA_KEY"].replace("\\n", "\n")

Row D is the answer I’d actually ship: don’t put the PEM in an env var at all. Keep the whole JSON key in a file, lock it down, and point the library at the path — no escaping, no shell-history exposure, nothing to un-mangle:

chmod 600 service-account.json          # -> 600 service-account.json
export GOOGLE_APPLICATION_CREDENTIALS="$PWD/service-account.json"

$ cat key.real | python3 validate.py
PARSED OK ✅  (key is usable)

The chmod 600 isn’t decoration. The default GOOGLE_APPLICATION_CREDENTIALS env var is read by every Google client library automatically, so the file is the credential — treat it like the private key it contains. Pasting the multi-line key into an env var also writes it into your shell history and, more often, into a CI log the moment something echos the environment. A file you never print can’t leak that way.

Bonus footgun: the ID that looks like an ID but isn’t

Once auth works, the Data API asks for a property in the form properties/<numeric id>. The number you want is the all-digits property ID from Admin → Property Settings. The thing you’ll grab by reflex is the G-XXXXXXX measurement ID — the gtag on your pages — because it’s the one you see all day. They are not the same value and one will not substitute for the other. I ran six candidates through a shape check:

'493819412'            -> numeric property ID ✅  (use properties/493819412)
'G-ABC1234XYZ'         -> measurement ID ❌  (that's the gtag, not the property)
'UA-11111-1'           -> stream/UA tag ❌  (still not the property)
'properties/493819412' -> not an ID the Data API takes ❌  (don't pre-prefix it)
'493819412x'           -> not an ID the Data API takes ❌

Note the fourth row: if the library wants a bare numeric ID and builds properties/<id> for you, handing it properties/493819412 yourself produces properties/properties/493819412. Read whether your client wants the number or the full resource string, once, on purpose.

The verdict, on the “survives a Tuesday” scale

• A normal Tuesday: you download the file, it says .apps.googleusercontent.com, you download the other file. The jq one-liner catches it in one command. Survivable.
• A bad Tuesday: the right key goes into an env var, the \n get flattened, and you lose an afternoon to a ValueError that blames “key data” and not the shell that mangled it. Survivable only if you already know to un-escape — or you never put the PEM in an env var and read the file instead.
• A Tuesday where the intern has sudo: a zero-byte credential passes a jq check that forgot -e, the service account was created but never granted Viewer on the property, and the measurement ID went in where the property ID goes. Three green checkmarks, zero working auth. Add -e, grant the account, and check the ID shape — each is one line, and each closes a failure that otherwise looks like success.

The pattern under all four failures is the same: this integration fails quietly, in your own files, before Google ever sees a request. The credential that’s the wrong kind, the key that’s the wrong encoding, the ID that’s the wrong field — none of them throw the error you’d hope for. So test the file, not your assumptions about it. Run the two one-liners above before you touch the network, and the thing that’s left to debug is an actual Google problem instead of a shell problem wearing Google’s error message.
